功用与百科/Brief Introduction：

机用户选用特有三通管装灌阀，可用来水剂和膏霜类药食同源产品的装灌，十分对高凝固点原物品（如浓酱、尖椒酱、番茄酱、种衣剂、微乳剂、飘浮剂等）的郊果相对特别，且计算精度提高。机用户选用PLC可程序编程掌握，和64英寸触模屏人与机器画质系统的，实现主动进瓶，主动装灌，主动出瓶，电器电线电缆，气动系统元机械部件均选用国际英文厂家，狠抓了精湛的性和经久安稳的性。本设施设施设备设施设备构造轻松，方法不方便，是目前中国人生理想的面对高凝固点原物品的装灌设施设施设备。机用户增配了以防滴漏问题问题与金属压模的装灌闷头，狠抓装灌结束以后后无滴漏问题问题，无金属压模。Filling valve, the machine USES special tee is suitable for the filling agent and cream products, especially for high viscosity material (such as thick sauce, chili sauce, tomato sauce, indicated, micro emulsion, suspending agent, etc.) of the effect is obvious, and high precision. The machine USES PLC programmable control, with 6 inch touch screen man-machine interface system, implements the automatic into the bottle, automatic filling, automatic bottle, electric, pneumatic components adopt international brand, to ensure that the performance of the outstanding quality and lasting stability. This equipment has simple structure, convenient operation, is the ideal filling equipment for high viscosity material. The machine is equipped with prevent drip with wire filling cocks, ensure filling after the completion of a drip-tight, no drawing.

特殊性/Characteristic：

◆管控软件性——用于三菱PLCPLC管控软件性，分装的用药量自由细调。Control system adopt mitsubishi PLC control system, filling dose random tweaks◆作业画质显示——69英寸彩屏手触式作业画质显示，形象直观简单易行、健康安全能信Interface - 6 inches color hand touch interface operation, intuitive and simple, safe and reliable◆基本性能加强——下料机有防漏滴系统设计，可随着废料特征参数掌握下潜装灌基本性能。（此基本性能就能够建议选用）Improvements - blanking drip tight device, according to the material properties have diving filling function. (this function can be chosen)◆小家电元器件封装——均选择香港国际有名的项目，提高认识机器设备的安全的牢靠、正确性强；Electrical components adopt international famous brand, to ensure the equipment safe and reliable, high accuracy;◆机械厂配件——服务器配件均进行优良304不锈碳钢作,如果有需要接受货品可以进行316L另计价用。Mechanical parts, machine parts are made of high quality 304 stainless steel material can be used if necessary contact 316 l in extra costs.◆计算器检验——立即计算器，对事业产出量客观投诉。Counting test, real-time, intuitive reflect the yield of work.◆包装检验——无瓶不灌、瓶数不是很不灌Bottle filling test - no bottle no filling, not enough◆运营维修情形——机器遵循GMP追求，可简单拆下来、清洁运营维修。Maintenance - the machine is in line with the GMP requirements, easy disassembly, cleaning maintenance.◆对换要求——换洗装灌要求时，只需要简单化设定，容易读懂。Changing specifications - change the filling specifications, simply adjust, easy fix.◆氛围系统运行氛围——系统运行氛围了氛围框架图，使刷卡机的操控氛围十分干净卫生防疫。（此氛围系统运行氛围还可以选型）Environmental protection configuration, configuration framework of environmental protection, make the operation of the machine environment more clean sanitation. (the environmental protection configuration can be selected)

技术性性能/technical parameters：

装灌头数The number of filling head	8头♔（可以4、6、8、10、1俩包装头）8 head (optional 4, 6, 8, 10, 12 filling head)
使用瓶径 Applicable bottles Drive	Ф33-Ф100 mm
检定控制精度measure precision	±1%
罐装余量Canned capacity	150-1000ml
生育水平Production Capacity	2400-4000瓶/分钟2400-4000   bottles per hour
气源压力bleed pressure	0.7-0.9mpa
电    源Power Supply	380 伏/50 HZ
总 功 率The total power	0.5 kw
外形尺寸 boundary dimension	6000×850×1800 mm
重    量Weight	500kg
