功能与详细介绍/Brief Introduction：

全一键液压泵式膏体酱分一键装机也是我集团公司认知市场上消费需求开发管理的新企业产品。设备通过SUS304装饰管液压泵式计量校准泵制定分装，且集一键上盖、一键旋盖、机电专业电力设备为一起，城市发展适用，征地赔偿占地小，多用途于化工环保、物品、农药杀菌剂、化工环保、化妆 品等领域的介质彩盒，完全符合GMP规程的要求。Automatic plunger paste paste filling machine is my company to meet the market demand, introduction of foreign advanced technology to develop new products. This machine adopts SUS304 stainless steel plunger metering pump filling, cover and set for automatic, automatic screw cap, integration of the mechanical and electrical, economical and practical, cover an area of an area small, widely used in pharmaceutical, food, pesticides, chemical industry, cosmetics and other industries of liquid packaging, full compliance with GMP requirements.

的特点/characteristic：

◆所主要包括柱塞泵式计量校准泵连接灌装设备，选用各方面胶状度夜体，高精度较高；泵的成分所主要包括快接式替换中介机构，更好地除污、消毒液。Adopt plunger type metering pump filling, used various viscosity liquid, high precision; The structure of pump adopts fast disassembly institutions, easy cleaning and disinfection◆液压泵式收费泵活塞杆环原料许多行业内及溶剂有效成分的许多所选择硅橡塑，四氟氯乙烯或许多原料，特种的场所所选择淘瓷原料。Plunger metering pump piston ring material according to the industry and different adopt silicon rubber, liquid ingredients tetrafluoroethylene or other material, special occasions with ceramic material◆PLC调控系统，直流变频空调控速，定时化因素高。PLC control system, frequency control of motor speed, a high degree of automation◆缺瓶不灌装生产线，会自动计数法用途。Lack of bottle filling, automatic counting function◆装量确定调节非常方便，可以次确定调节都是检定泵的充填量，也可应对很多检定泵确定微幅确定调节；运作简便方法，确定调节最快。The load adjustment is convenient, can be a filling quantity of all pumps also can be slightly adjusted according to various metering pump; Simple operation, rapid adjustment◆装灌针头配有防滴漏问题裝置，充填时前往瓶底装灌，速度慢升，控制泡泡。Filling needles a drip-proof device, filling into the bottom of the bottle filling, slowly rising and prevent bubbles.◆组装机可用于有差异 规格型号的塑料瓶，变动简单便捷，可在短时光间内实现。The machine is suitable for various specifications of bottles, easy adjustment, it can be finished in a short period of time◆一整台机器的按GMP规范要求规划。The machine designed according to the requirements of GMP

的技术性能/technic parameter：

适用人群玻璃瓶規格Size of bottles	20-1000ml（基于要生产厂家）20-1000 - ml (according to your need）
用于空瓶厚度Apply the bottle diameter	¢20-¢150mm
适用于盖子样式Apply the lid specifications	¢20-¢70mm
生产销售力量 production capacity	四头罐装：1000-2500瓶/个小时 Four filling head: 1000-2500 bottles per hour 八头灌装生产线：2500-4000瓶/小 Eight head filling: 2500-4000 bottles per hour 12头灌装设备：4000-6000瓶/H 12 head filling: 4000-6000 bottles per hour
装量计算误差The load error	±1%
旋盖优秀率率Screw cover percent of pass	≥99%
电power supply	380V，50HZ
输出power	3.0KW
气动阀门gas sources	0.4-0.75MPA
高速度操控speed control	变频柜变频调速variable speed
